AGRICULTURAL MACHINERY
Snow plough SAME VPX
Technical information
The Optimal® VPX plow is designed to work in heavier snow conditions and clear large areas. The VPX plow is suitable for attachment to large tractors and wheel loaders. The VPX saw has a spring-protected cutting edge that constantly presses the surface to be cleaned. The working position of the cutting blade is also restored with the help of springs after the blade tilts due to resistance. This solution reduces the vibration of the cutting blade, which enables a higher working speed and reduces fuel consumption. The VPX saw has a hydraulic accumulator, which restores the blade from collisions caused by obstacles and the correct position of the saw. Stands are standard equipment.Benefits
The shape of the blade ensures good performance and prevents snow from sticking
Hydraulic shock protection with connected hydraulic accumulator
HARDOX steel brackets
The new VPX series models replace the previous VP and VPT models. The blade/blade of the new series of articulated plows is designed with a +15º positive angle, which ensures a better result. The shape of the cover has also been updated.
All VPX plows have an integrated "floating" hitch solution. The movement range of the plow covers is ±38º, which ensures a smaller width for the plows in the transport position.
| Model: | VPX 180 | VPX 220 | VPX 260 | VPX 290 | VPX 330 | VPX 370 |
| Height(cm): | 70 | 70 | 87 | 87 | 105 | 113 |
| Working width(cm): | 180 | 220 | 260 | 290 | 330 | 370 |
| Working width in V- position (cm): | 150 | 185 | 200 | 225 | 247 | 280 |
| Control (hydraulically/el): | + | + | + | + | + | + |
| Diogonal flapp: | can be ordered | standard | standard | standard | standard | standard |
| Rangae of plow movement: | ±38º | ±38º | ±38º | ±38º | ±38º | ±38º |
| Positive angle of the plow: | +15º | +15º | +15º | +15º | +15º | +15º |
| Weight (kg): | 430 | 490 | 590 | 660 | 750 | 910 |
