AGRICULTURAL MACHINERY
Flail mower Peruzzo JAGUAR
Technical information
The roller crusher Peruzzo Jaguar is designed for processing sports and golf courses. The machine cuts, cuts vertically and collects in one go. The cutting height can be adjusted to the nearest millimeter. The roller shredder is attached to a 3-point lifting device or tiller behind the tractor. The size of the collection tanks is between 1300 and 2100 liters. The emptying height of the tanks is 2.1m. Power requirement from 40 hp to 70 hp. The shredder is equipped with very fine Paddle blades, to which a vertical cutting blade can also be attached. Thanks to the very high-quality blades and the high rotation speed of the roller, the shredder is also suitable for sports and golf courses. Vertical cutting depth up to 40 mm. Adjusting the mowing height is really easy and effortless with the rear roller and front support wheels.| Model | Working width (mm) | Power requirement (HP/kW) | Power requirement (HP/kW model with transport wheels) | Flails (pcs) | Weigth (kg) | PTO shaft (rpm) | Measurements |
| JAGUAR 1200 | 1200 | 40/30 | 20/15 | 38 | 625 | 540-1000 | 145x200x160 |
| JAGUAR 1600 | 1600 | 50/37 | 33/25 | 48 | 710 | 540-1000 | 175x200x160 |
| JAGUAR 1800 | 1800 | 60/44 | 47/35 | 58 | 800 | 540-1000 | 215x200x160 |
| JAGUAR 2000 | 2000 | 70/52 | 60/45 | 64 | 900 | 540-1000 | 235x200x160 |
