Technical information
The main purpose of compaction rollers is soil preparation for sowing. Producced in variety of 5 to 6 m with crossboards or without them. Soil leveling, clods crushing and cultivated surface compaction is what it is for. Compaction rollers are manufactured with a Cambridge-type rings. Also cultivation intensity can be adjusted hydraulically from the cab.
| Model: |
TV-5 |
TV-5LH |
TV-6 |
TV-6LH |
| Working width: |
5m |
5m |
6m |
6m |
| Ironing board adjustment: |
- |
Hydraulic |
- |
Hydraulic |
| Number of sections: |
3 |
3 |
3 |
3 |
| Cambridge rings 510mm |
52 |
52 |
60 |
60 |
| Narrow rings 530mm |
48 |
48 |
54 |
54 |
| Complete set: |
Without ironing boards |
With ironing boards |
Without ironing boards |
With ironing boards |
| Working speed: |
till 12 km/h |
till 12 km/h |
till 12 km/h |
till 12 km/h |
| Wheels: |
260/75- 15,3 |
260/75- 15,3 |
260/75- 15,3 |
260/75- 15,3 |
| Minimum tractor power: |
From 90hp |
From 100hp |
From 110hp |
From 125hp |
