AGRICULTURAL MACHINERY
Tractor Solis 26 HST with cab
Technical information
The T273 is the more powerful twin of the T233, with same advanced ergonomics and usability but with an extra something under the hood. The T273 also has optional turf tires. Utilizing category I implements, whether it's for the golf course or the landscaping this unit will get the job done, in style!Model | T273HST |
Engine Manufacturer | Mitsubishi |
Engine Model | S3L2 |
Engine(kw)-Gross | 19.8 |
PTO (kw) | 15.4 |
Rated engine speed (rpm) | 2700 |
Number of cylinders (pcs) | 3 |
Air Cleaner | Dual Dry |
Alternator | 12V/50A |
Fuel System Type | Indirect Fuel Injection |
Powertrain | |
Transmission type | HST |
Number of Speeds | Infinite / 2 Range |
Max.Travelling speed (km/h) | 17 |
Brakes | Wet Disc |
Steering | Hydrostatic |
Clutch | N/A |
Hydraulic system | |
Pump type | Dual Gear Pump |
Implement pump (L/Min) | 18.9 |
Steering pump | 10 |
Max Total flow | 28.9 |
Category, 3 Point Hitch | 1 |
Hitch lift capacity (kg) | 700 |
Lift Control type | Position |
Joy Stick Valve | Standard |
No. of standard remote valves-option | 1 |
PTO | |
PTO Type | Independent |
PTO Control | Electric/Hydro |
PTO Mid-Option (rpm) | 2000 |
PTO Rear (rpm) | 540 |
PTO Shaft Diameter (mm) | 35 |
Capacities | |
Fuel Tank (L) | 25 |
Cooling system (L) | 8.8 |
Crankcase (with filter) (L) | 5.7 |
Trans & Hydr. System (L) | 36 |
Front Axle (L) | 8.2 |
Dimensions | |
Overall length (mm) with 3P | 2740 |
Overall width (mm) | 1342 |
Wheelbase (mm) | 1480 |
Height to top of ROPS (mm) | 2020 |
Min. Ground Cleareance (mm) | 196 |
Min. Turn Radius (mm) with Brakes | 2502 |
Min. Turn Radius (mm) w/o brakes | 2682 |
Total Weight (kg) | 865 |
