AGRICULTURAL MACHINERY
Livestock trailer Dinapolis TRV
Technical information
TRV semi-trailer for animal transportation. The chassis of the semi-trailer is hydraulic, with a hydraulic brake system acting on all wheels. The semi-trailer is equipped with lightning devices and light alarms. The semi-trailer is aggregated with tractors that have a permissible coupling device load of no less than 1500 kg and are equipped with a hydraulic/pneumatic brake control system. The body of the semi-trailer is of welded construction. This livestock trailer was designed farmers who look for an easy and quick ways to carry animals.| Model | TRV-5.10 | TRV-6.35 | TRV-7.60 | TRV-8.85 | TRV-11.35 |
| Max.length (m) | 6.60 | 7.85 | 9.10 | 10.35 | 12.85 |
| Width (m) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 |
| Standard wheels | 400/60-15,5 | 400/60-15,5 | 400/60-15,5 | 400/60-15,5 | 400/60-15,5 |
| Chassis type | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic |
| Power demand | 80-90 | 80-90 | 80-90 | 100-110 | 120-130 |
| Other type wheels | - | 520/50-17 | 520/50-17 | 520/50-17 | 520/50-17 |
- side door in the left or right
- slide door in the left or right
- extra wheels
- Hydraulic bridge system
- Tarpaulin roof
Optional equipment can be ordered:
- 2 colors in the color selection
- Rear ramp
- Sliding door on the right
- Sliding door on the left
- To the side on the right
- To the left side
- To the side in the back
- 1-4 partitions (doors)
- anti-slip floor
